TUBING&CASING
share
Out Diameter:
Tubing: OD 2 3/8" - 4 1/2" (60.3mm-114.30mm)
Casing: OD 4 1/2"- 20" (114.3mm-508mm)
Wall Thickness: 0. 205"- 0.635"
Length: R1(4.88mtr-7.62mtr), R2(7.62mtr-10.36mtr), R3(10.36mtr or longer)
Grade: J55/K55/N80/L80/P110/C95/T95/Q125/L80-13CR/P110- 13CR/80S/80SS/95S/
95SS/P110S/P110SS
Tubing: OD 2 3/8" - 4 1/2" (60.3mm-114.30mm)
Casing: OD 4 1/2"- 20" (114.3mm-508mm)
Wall Thickness: 0. 205"- 0.635"
Length: R1(4.88mtr-7.62mtr), R2(7.62mtr-10.36mtr), R3(10.36mtr or longer)
Grade: J55/K55/N80/L80/P110/C95/T95/Q125/L80-13CR/P110- 13CR/80S/80SS/95S/
95SS/P110S/P110SS
Detail
Process: ERW and Seamless
Standard: API 5CT
Surface: Corrosion proofing water based paint
Tubing Ends:Beveled, Square Cut, With NUE/EUE/IJ/PREMIUM Connection
Casing Ends: Beveled, Square Cut, With LTC/STC/BTC/PREMIUM Connection
Packing: Protection Caps in Both Ends, Waterproof Paper Wrapped, Two Tags
Heat treatment: Normalized, Quencher+Temper
